OPERATION CLASS
D
NUMBER OF CHANNELS
1
INPUT SENSITIVITY
220mV
SIGNAL TO NOISE RATIO
>88dB
FREQUENCY RESPONSE
10Hz ~ 20KHz (-3dB)
CROSSOVER HIGH PASS (HPF)
10Hz ~ 80 Hz (-12dB/8ª) Variable
CROSSOVER LOW PASS (LPF)
80Hz ~ Full (-12dB/8ª) Variable
INPUT IMPEDANCE
10K Ohms
OUTPUT IMPEDANCE
1 OHM
PROTECTION SYSTEM
Output Short circuit / High or Low supply voltage / Thermal protection
MINIMUM SUPPLY VOLTAGE
9 VDC
MAXIMUM SUPPLY VOLTAGE
16 VDC
CONSUMPTION AT REST
1.5A
MAXIMUM MUSIC CONSUMPTION
@12,6VDC: 117.5A
