Manufacturer Manual (Please refer for Warranty and other conditions)
OPERATION CLASS
Class D
NUMBER OF CHANNELS
1
MAXIMUM POWER
Nominal Power @12.6VDC 1 Ohm: 3000W RMS 2 Ohms: 3000W RMS 4 Ohms: 2000W RMS
INPUT SENSITIVITY
0.22V ~ 4V
SIGNAL TO NOISE RATIO
>90dB
FREQUENCY RESPONSE
10Hz ~ 10KHz (-3dB)
CROSSOVER HIGH PASS (HPF)
10Hz ~ 90Hz (-12dB/8ª) Variable
CROSSOVER LOW PASS (LPF)
90Hz ~ 10KHz (-12dB/8ª) Variable
INPUT IMPEDANCE
10K Ohms
OUTPUT IMPEDANCE
1 ~2 ohms
PROTECTION SYSTEM
Output short circuit low/high voltage protection thermal protection
MINIMUM SUPPLY VOLTAGE
9VDC
MAXIMUM SUPPLY VOLTAGE
16VDC
CONSUMPTION AT REST
2.40A
MAXIMUM MUSIC CONSUMPTION
150A
MAXIMUM CONSUMPTION IN SINUSOIDAL SIGNAL
300A
