Manufacturer Manual (Please refer for Warranty and other conditions)
OPERATION CLASS
Class D
NUMBER OF CHANNELS
4
MAXIMUM POWER
@ 13,8 VDC - 2 OHMS - 400 W RMS (4 x 100W RMS) @ 13,8 VDC - 4 OHMS - 252 W RMS (4 x 63W RMS) Bridge @ 13,8 VDC - 4 OHMS - 400W RMS (2 x 200W RMS)
INPUT SENSITIVITY
200mV (Vol = max.)
SIGNAL TO NOISE RATIO
> 90dB
FREQUENCY RESPONSE
(Full Range): 18 Hz to 30 kHz (-1dB)
CROSSOVER HIGH PASS (HPF)
90 Hz (-12dB/8th)
CROSSOVER LOW PASS (LPF)
90 Hz (-12dB/8th)
INPUT IMPEDANCE
22K ohms
OUTPUT IMPEDANCE
2 ohms
PROTECTION SYSTEM
Thermal and Output Short
MINIMUM SUPPLY VOLTAGE
8 VDC
MAXIMUM SUPPLY VOLTAGE
16 VDC
CONSUMPTION AT REST
0.8A
MAXIMUM MUSIC CONSUMPTION
@13,8VDC: 16.5A
MAXIMUM CONSUMPTION IN SINUSOIDAL SIGNAL
@13,8VDC: 33A
